This Auto Edge Guidance Unit is a very compact unit that will fit into the web path on your corrugator machine. Where you require the moving web to be held in control and maintain automatically. While aligning your web which is especially important to the quality of your product for maximum productivity.

Auto Edge Guidance

This machine only requires a small footprint to fit into your existing production line, even for the multi-web units. These machines will hold your product edge alignment to remarkably close limits while running at fast speeds. With the use of this auto edge guidance unit, deploying leading edge web guiding technologies.

Here are the benefits you will experience from day one with these machines…!

Fast Auto Edge Guidance Paper Width Changes with ZERO SET-UP

• Accurately Aligns all papers to +/- 1 mm.
• Patented InfraRed paper position sensors
• Smooth S/F Tension control without the need for any Vacuum Brake units
• No Dust or Noise generated
• No Slide Guides or associate assemblies to position or maintain
• Easy Installations
• Paper Widths from 1400 up to 2800 mm.



The principle behind the operation of this machine is an incredibly unique system and requires no manual guide units to fit or set up at any time.

So, less work for the operators to have to attend to while setting up or changing new orders of different web widths.



Once this Auto Edge Guidance Unit is set up, the operators will not need to change or alter anything on the machine at any time.





Pre-Heater Auto Edge Guidance Unit

This machine is truly fully automated and is only one of the very few devices that you can leave and forget about.



The only thing that the operators need to do is occasionally clean the dust off the sensor heads with a clean cloth when running mixed fibre materials.
